cgltf.h File Reference
#include <stddef.h>
+ Include dependency graph for cgltf.h:

Go to the source code of this file.

Classes

struct  cgltf_memory_options

struct  cgltf_file_options

struct  cgltf_options

struct  cgltf_extras

struct  cgltf_extension

struct  cgltf_buffer

struct  cgltf_meshopt_compression

struct  cgltf_buffer_view

struct  cgltf_accessor_sparse

struct  cgltf_accessor

struct  cgltf_attribute

struct  cgltf_image

struct  cgltf_sampler

struct  cgltf_texture

struct  cgltf_texture_transform

struct  cgltf_texture_view

struct  cgltf_pbr_metallic_roughness

struct  cgltf_pbr_specular_glossiness

struct  cgltf_clearcoat

struct  cgltf_transmission

struct  cgltf_ior

struct  cgltf_specular

struct  cgltf_volume

struct  cgltf_sheen

struct  cgltf_emissive_strength

struct  cgltf_iridescence

struct  cgltf_material

struct  cgltf_material_mapping

struct  cgltf_morph_target

struct  cgltf_draco_mesh_compression

struct  cgltf_mesh_gpu_instancing

struct  cgltf_primitive

struct  cgltf_mesh

struct  cgltf_skin

struct  cgltf_camera_perspective

struct  cgltf_camera_orthographic

struct  cgltf_camera

struct  cgltf_light

struct  cgltf_node

struct  cgltf_scene

struct  cgltf_animation_sampler

struct  cgltf_animation_channel

struct  cgltf_animation

struct  cgltf_material_variant

struct  cgltf_asset

struct  cgltf_data


Typedefs

typedef size_t cgltf_size

typedef long long int cgltf_ssize

typedef float cgltf_float

typedef int cgltf_int

typedef unsigned int cgltf_uint

typedef int cgltf_bool

typedef enum cgltf_file_type cgltf_file_type

typedef enum cgltf_result cgltf_result

typedef struct cgltf_memory_options cgltf_memory_options

typedef struct cgltf_file_options cgltf_file_options

typedef struct cgltf_options cgltf_options

typedef enum cgltf_buffer_view_type cgltf_buffer_view_type

typedef enum cgltf_attribute_type cgltf_attribute_type

typedef enum cgltf_component_type cgltf_component_type

typedef enum cgltf_type cgltf_type

typedef enum cgltf_primitive_type cgltf_primitive_type

typedef enum cgltf_alpha_mode cgltf_alpha_mode

typedef enum
cgltf_animation_path_type
cgltf_animation_path_type

typedef enum
cgltf_interpolation_type
cgltf_interpolation_type

typedef enum cgltf_camera_type cgltf_camera_type

typedef enum cgltf_light_type cgltf_light_type

typedef enum cgltf_data_free_method cgltf_data_free_method

typedef struct cgltf_extras cgltf_extras

typedef struct cgltf_extension cgltf_extension

typedef struct cgltf_buffer cgltf_buffer

typedef enum
cgltf_meshopt_compression_mode
cgltf_meshopt_compression_mode

typedef enum
cgltf_meshopt_compression_filter
cgltf_meshopt_compression_filter

typedef struct
cgltf_meshopt_compression
cgltf_meshopt_compression

typedef struct cgltf_buffer_view cgltf_buffer_view

typedef struct
cgltf_accessor_sparse
cgltf_accessor_sparse

typedef struct cgltf_accessor cgltf_accessor

typedef struct cgltf_attribute cgltf_attribute

typedef struct cgltf_image cgltf_image

typedef struct cgltf_sampler cgltf_sampler

typedef struct cgltf_texture cgltf_texture

typedef struct
cgltf_texture_transform
cgltf_texture_transform

typedef struct cgltf_texture_view cgltf_texture_view

typedef struct
cgltf_pbr_metallic_roughness
cgltf_pbr_metallic_roughness

typedef struct
cgltf_pbr_specular_glossiness
cgltf_pbr_specular_glossiness

typedef struct cgltf_clearcoat cgltf_clearcoat

typedef struct cgltf_transmission cgltf_transmission

typedef struct cgltf_ior cgltf_ior

typedef struct cgltf_specular cgltf_specular

typedef struct cgltf_volume cgltf_volume

typedef struct cgltf_sheen cgltf_sheen

typedef struct
cgltf_emissive_strength
cgltf_emissive_strength

typedef struct cgltf_iridescence cgltf_iridescence

typedef struct cgltf_material cgltf_material

typedef struct
cgltf_material_mapping
cgltf_material_mapping

typedef struct cgltf_morph_target cgltf_morph_target

typedef struct
cgltf_draco_mesh_compression
cgltf_draco_mesh_compression

typedef struct
cgltf_mesh_gpu_instancing
cgltf_mesh_gpu_instancing

typedef struct cgltf_primitive cgltf_primitive

typedef struct cgltf_mesh cgltf_mesh

typedef struct cgltf_node cgltf_node

typedef struct cgltf_skin cgltf_skin

typedef struct
cgltf_camera_perspective
cgltf_camera_perspective

typedef struct
cgltf_camera_orthographic
cgltf_camera_orthographic

typedef struct cgltf_camera cgltf_camera

typedef struct cgltf_light cgltf_light

typedef struct cgltf_scene cgltf_scene

typedef struct
cgltf_animation_sampler
cgltf_animation_sampler

typedef struct
cgltf_animation_channel
cgltf_animation_channel

typedef struct cgltf_animation cgltf_animation

typedef struct
cgltf_material_variant
cgltf_material_variant

typedef struct cgltf_asset cgltf_asset

typedef struct cgltf_data cgltf_data


Enumerations

enum  cgltf_file_type { cgltf_file_type_invalid, cgltf_file_type_gltf, cgltf_file_type_glb, cgltf_file_type_max_enum }

enum  cgltf_result {
  cgltf_result_success, cgltf_result_data_too_short, cgltf_result_unknown_format, cgltf_result_invalid_json,
  cgltf_result_invalid_gltf, cgltf_result_invalid_options, cgltf_result_file_not_found, cgltf_result_io_error,
  cgltf_result_out_of_memory, cgltf_result_legacy_gltf, cgltf_result_max_enum
}

enum  cgltf_buffer_view_type { cgltf_buffer_view_type_invalid, cgltf_buffer_view_type_indices, cgltf_buffer_view_type_vertices, cgltf_buffer_view_type_max_enum }

enum  cgltf_attribute_type {
  cgltf_attribute_type_invalid, cgltf_attribute_type_position, cgltf_attribute_type_normal, cgltf_attribute_type_tangent,
  cgltf_attribute_type_texcoord, cgltf_attribute_type_color, cgltf_attribute_type_joints, cgltf_attribute_type_weights,
  cgltf_attribute_type_custom, cgltf_attribute_type_max_enum
}

enum  cgltf_component_type {
  cgltf_component_type_invalid, cgltf_component_type_r_8, cgltf_component_type_r_8u, cgltf_component_type_r_16,
  cgltf_component_type_r_16u, cgltf_component_type_r_32u, cgltf_component_type_r_32f, cgltf_component_type_max_enum
}

enum  cgltf_type {
  cgltf_type_invalid, cgltf_type_scalar, cgltf_type_vec2, cgltf_type_vec3,
  cgltf_type_vec4, cgltf_type_mat2, cgltf_type_mat3, cgltf_type_mat4,
  cgltf_type_max_enum
}

enum  cgltf_primitive_type {
  cgltf_primitive_type_points, cgltf_primitive_type_lines, cgltf_primitive_type_line_loop, cgltf_primitive_type_line_strip,
  cgltf_primitive_type_triangles, cgltf_primitive_type_triangle_strip, cgltf_primitive_type_triangle_fan, cgltf_primitive_type_max_enum
}

enum  cgltf_alpha_mode { cgltf_alpha_mode_opaque, cgltf_alpha_mode_mask, cgltf_alpha_mode_blend, cgltf_alpha_mode_max_enum }

enum  cgltf_animation_path_type {
  cgltf_animation_path_type_invalid, cgltf_animation_path_type_translation, cgltf_animation_path_type_rotation, cgltf_animation_path_type_scale,
  cgltf_animation_path_type_weights, cgltf_animation_path_type_max_enum
}

enum  cgltf_interpolation_type { cgltf_interpolation_type_linear, cgltf_interpolation_type_step, cgltf_interpolation_type_cubic_spline, cgltf_interpolation_type_max_enum }

enum  cgltf_camera_type { cgltf_camera_type_invalid, cgltf_camera_type_perspective, cgltf_camera_type_orthographic, cgltf_camera_type_max_enum }

enum  cgltf_light_type {
  cgltf_light_type_invalid, cgltf_light_type_directional, cgltf_light_type_point, cgltf_light_type_spot,
  cgltf_light_type_max_enum
}

enum  cgltf_data_free_method { cgltf_data_free_method_none, cgltf_data_free_method_file_release, cgltf_data_free_method_memory_free, cgltf_data_free_method_max_enum }

enum  cgltf_meshopt_compression_mode {
  cgltf_meshopt_compression_mode_invalid, cgltf_meshopt_compression_mode_attributes, cgltf_meshopt_compression_mode_triangles, cgltf_meshopt_compression_mode_indices,
  cgltf_meshopt_compression_mode_max_enum
}

enum  cgltf_meshopt_compression_filter {
  cgltf_meshopt_compression_filter_none, cgltf_meshopt_compression_filter_octahedral, cgltf_meshopt_compression_filter_quaternion, cgltf_meshopt_compression_filter_exponential,
  cgltf_meshopt_compression_filter_max_enum
}


Functions

cgltf_result cgltf_parse (const cgltf_options *options, const void *data, cgltf_size size, cgltf_data **out_data)

cgltf_result cgltf_parse_file (const cgltf_options *options, const char *path, cgltf_data **out_data)

cgltf_result cgltf_load_buffers (const cgltf_options *options, cgltf_data *data, const char *gltf_path)

cgltf_result cgltf_load_buffer_base64 (const cgltf_options *options, cgltf_size size, const char *base64, void **out_data)

cgltf_size cgltf_decode_string (char *string)

cgltf_size cgltf_decode_uri (char *uri)

cgltf_result cgltf_validate (cgltf_data *data)

void cgltf_free (cgltf_data *data)

void cgltf_node_transform_local (const cgltf_node *node, cgltf_float *out_matrix)

void cgltf_node_transform_world (const cgltf_node *node, cgltf_float *out_matrix)

cgltf_bool cgltf_accessor_read_float (const cgltf_accessor *accessor, cgltf_size index, cgltf_float *out, cgltf_size element_size)

cgltf_bool cgltf_accessor_read_uint (const cgltf_accessor *accessor, cgltf_size index, cgltf_uint *out, cgltf_size element_size)

cgltf_size cgltf_accessor_read_index (const cgltf_accessor *accessor, cgltf_size index)

cgltf_size cgltf_num_components (cgltf_type type)

cgltf_size cgltf_accessor_unpack_floats (const cgltf_accessor *accessor, cgltf_float *out, cgltf_size float_count)

cgltf_result cgltf_copy_extras_json (const cgltf_data *data, const cgltf_extras *extras, char *dest, cgltf_size *dest_size)


Typedef Documentation

typedef struct cgltf_asset cgltf_asset
typedef int cgltf_bool

Definition at line 106 of file cgltf.h.

typedef struct cgltf_buffer cgltf_buffer
typedef struct cgltf_camera cgltf_camera
typedef struct cgltf_data cgltf_data
typedef struct cgltf_extras cgltf_extras
typedef float cgltf_float

Definition at line 103 of file cgltf.h.

typedef struct cgltf_image cgltf_image
typedef int cgltf_int

Definition at line 104 of file cgltf.h.

typedef struct cgltf_ior cgltf_ior
typedef struct cgltf_light cgltf_light
typedef struct cgltf_mesh cgltf_mesh
typedef struct cgltf_node cgltf_node

Definition at line 599 of file cgltf.h.

typedef struct cgltf_options cgltf_options
typedef enum cgltf_result cgltf_result
typedef struct cgltf_sampler cgltf_sampler
typedef struct cgltf_scene cgltf_scene
typedef struct cgltf_sheen cgltf_sheen
typedef size_t cgltf_size

cgltf - a single-file glTF 2.0 parser written in C99.

Version: 1.13

Website: https://github.com/jkuhlmann/cgltf

Distributed under the MIT License, see notice at the end of this file.

Building: Include this file where you need the struct and function declarations. Have exactly one source file where you define CGLTF_IMPLEMENTATION before including this file to get the function definitions.

Reference: cgltf_result cgltf_parse(const cgltf_options*, const void*, cgltf_size, cgltf_data**) parses both glTF and GLB data. If this function returns cgltf_result_success, you have to call cgltf_free() on the created cgltf_data* variable. Note that contents of external files for buffers and images are not automatically loaded. You'll need to read these files yourself using URIs in the cgltf_data structure.

cgltf_options is the struct passed to cgltf_parse() to control parts of the parsing process. You can use it to force the file type and provide memory allocation as well as file operation callbacks. Should be zero-initialized to trigger default behavior.

cgltf_data is the struct allocated and filled by cgltf_parse(). It generally mirrors the glTF format as described by the spec (see https://github.com/KhronosGroup/glTF/tree/master/specification/2.0).

void cgltf_free(cgltf_data*) frees the allocated cgltf_data variable.

cgltf_result cgltf_load_buffers(const cgltf_options*, cgltf_data*, const char* gltf_path) can be optionally called to open and read buffer files using the FILE* APIs. The gltf_path argument is the path to the original glTF file, which allows the parser to resolve the path to buffer files.

cgltf_result cgltf_load_buffer_base64(const cgltf_options* options, cgltf_size size, const char* base64, void** out_data) decodes base64-encoded data content. Used internally by cgltf_load_buffers(). This is useful when decoding data URIs in images.

cgltf_result cgltf_parse_file(const cgltf_options* options, const char* path, cgltf_data** out_data) can be used to open the given file using FILE* APIs and parse the data using cgltf_parse().

cgltf_result cgltf_validate(cgltf_data*) can be used to do additional checks to make sure the parsed glTF data is valid.

cgltf_node_transform_local converts the translation / rotation / scale properties of a node into a mat4.

cgltf_node_transform_world calls cgltf_node_transform_local on every ancestor in order to compute the root-to-node transformation.

cgltf_accessor_unpack_floats reads in the data from an accessor, applies sparse data (if any), and converts them to floating point. Assumes that cgltf_load_buffers has already been called. By passing null for the output pointer, users can find out how many floats are required in the output buffer.

cgltf_num_components is a tiny utility that tells you the dimensionality of a certain accessor type. This can be used before cgltf_accessor_unpack_floats to help allocate the necessary amount of memory.

cgltf_accessor_read_float reads a certain element from a non-sparse accessor and converts it to floating point, assuming that cgltf_load_buffers has already been called. The passed-in element size is the number of floats in the output buffer, which should be in the range [1, 16]. Returns false if the passed-in element_size is too small, or if the accessor is sparse.

cgltf_accessor_read_uint is similar to its floating-point counterpart, but limited to reading vector types and does not support matrix types. The passed-in element size is the number of uints in the output buffer, which should be in the range [1, 4]. Returns false if the passed-in element_size is too small, or if the accessor is sparse.

cgltf_accessor_read_index is similar to its floating-point counterpart, but it returns size_t and only works with single-component data types.

cgltf_result cgltf_copy_extras_json(const cgltf_data*, const cgltf_extras*, char* dest, cgltf_size* dest_size) allows users to retrieve the "extras" data that can be attached to many glTF objects (which can be arbitrary JSON data). The cgltf_extras struct stores the offsets of the start and end of the extras JSON data as it appears in the complete glTF JSON data. This function copies the extras data into the provided buffer. If dest is NULL, the length of the data is written into dest_size. You can then parse this data using your own JSON parser or, if you've included the cgltf implementation using the integrated JSMN JSON parser.

Definition at line 101 of file cgltf.h.

typedef struct cgltf_skin cgltf_skin
typedef long long int cgltf_ssize

Definition at line 102 of file cgltf.h.

typedef struct cgltf_texture cgltf_texture
typedef enum cgltf_type cgltf_type
typedef unsigned int cgltf_uint

Definition at line 105 of file cgltf.h.

typedef struct cgltf_volume cgltf_volume

Enumeration Type Documentation

Enumerator
cgltf_alpha_mode_opaque
cgltf_alpha_mode_mask
cgltf_alpha_mode_blend
cgltf_alpha_mode_max_enum

Definition at line 212 of file cgltf.h.

Enumerator
cgltf_animation_path_type_invalid
cgltf_animation_path_type_translation
cgltf_animation_path_type_rotation
cgltf_animation_path_type_scale
cgltf_animation_path_type_weights
cgltf_animation_path_type_max_enum

Definition at line 220 of file cgltf.h.

Enumerator
cgltf_attribute_type_invalid
cgltf_attribute_type_position
cgltf_attribute_type_normal
cgltf_attribute_type_tangent
cgltf_attribute_type_texcoord
cgltf_attribute_type_color
cgltf_attribute_type_joints
cgltf_attribute_type_weights
cgltf_attribute_type_custom
cgltf_attribute_type_max_enum

Definition at line 161 of file cgltf.h.

Enumerator
cgltf_buffer_view_type_invalid
cgltf_buffer_view_type_indices
cgltf_buffer_view_type_vertices
cgltf_buffer_view_type_max_enum

Definition at line 153 of file cgltf.h.

Enumerator
cgltf_camera_type_invalid
cgltf_camera_type_perspective
cgltf_camera_type_orthographic
cgltf_camera_type_max_enum

Definition at line 236 of file cgltf.h.

Enumerator
cgltf_component_type_invalid
cgltf_component_type_r_8
cgltf_component_type_r_8u
cgltf_component_type_r_16
cgltf_component_type_r_16u
cgltf_component_type_r_32u
cgltf_component_type_r_32f
cgltf_component_type_max_enum

Definition at line 175 of file cgltf.h.

Enumerator
cgltf_data_free_method_none
cgltf_data_free_method_file_release
cgltf_data_free_method_memory_free
cgltf_data_free_method_max_enum

Definition at line 251 of file cgltf.h.

Enumerator
cgltf_file_type_invalid
cgltf_file_type_gltf
cgltf_file_type_glb
cgltf_file_type_max_enum

Definition at line 108 of file cgltf.h.

Enumerator
cgltf_interpolation_type_linear
cgltf_interpolation_type_step
cgltf_interpolation_type_cubic_spline
cgltf_interpolation_type_max_enum

Definition at line 229 of file cgltf.h.

Enumerator
cgltf_light_type_invalid
cgltf_light_type_directional
cgltf_light_type_point
cgltf_light_type_spot
cgltf_light_type_max_enum

Definition at line 243 of file cgltf.h.

Enumerator
cgltf_meshopt_compression_filter_none
cgltf_meshopt_compression_filter_octahedral
cgltf_meshopt_compression_filter_quaternion
cgltf_meshopt_compression_filter_exponential
cgltf_meshopt_compression_filter_max_enum

Definition at line 288 of file cgltf.h.

Enumerator
cgltf_meshopt_compression_mode_invalid
cgltf_meshopt_compression_mode_attributes
cgltf_meshopt_compression_mode_triangles
cgltf_meshopt_compression_mode_indices
cgltf_meshopt_compression_mode_max_enum

Definition at line 280 of file cgltf.h.

Enumerator
cgltf_primitive_type_points
cgltf_primitive_type_lines
cgltf_primitive_type_line_loop
cgltf_primitive_type_line_strip
cgltf_primitive_type_triangles
cgltf_primitive_type_triangle_strip
cgltf_primitive_type_triangle_fan
cgltf_primitive_type_max_enum

Definition at line 200 of file cgltf.h.

Enumerator
cgltf_result_success
cgltf_result_data_too_short
cgltf_result_unknown_format
cgltf_result_invalid_json
cgltf_result_invalid_gltf
cgltf_result_invalid_options
cgltf_result_file_not_found
cgltf_result_io_error
cgltf_result_out_of_memory
cgltf_result_legacy_gltf
cgltf_result_max_enum

Definition at line 116 of file cgltf.h.

enum cgltf_type
Enumerator
cgltf_type_invalid
cgltf_type_scalar
cgltf_type_vec2
cgltf_type_vec3
cgltf_type_vec4
cgltf_type_mat2
cgltf_type_mat3
cgltf_type_mat4
cgltf_type_max_enum

Definition at line 187 of file cgltf.h.

Function Documentation

cgltf_bool cgltf_accessor_read_float ( const cgltf_accessor accessor,
cgltf_size  index,
cgltf_float out,
cgltf_size  element_size
)
cgltf_size cgltf_accessor_read_index ( const cgltf_accessor accessor,
cgltf_size  index
)
cgltf_bool cgltf_accessor_read_uint ( const cgltf_accessor accessor,
cgltf_size  index,
cgltf_uint out,
cgltf_size  element_size
)
cgltf_size cgltf_accessor_unpack_floats ( const cgltf_accessor accessor,
cgltf_float out,
cgltf_size  float_count
)
cgltf_result cgltf_copy_extras_json ( const cgltf_data data,
const cgltf_extras extras,
char *  dest,
cgltf_size dest_size
)
cgltf_size cgltf_decode_string ( char *  string)
cgltf_size cgltf_decode_uri ( char *  uri)
void cgltf_free ( cgltf_data data)
cgltf_result cgltf_load_buffer_base64 ( const cgltf_options options,
cgltf_size  size,
const char *  base64,
void **  out_data
)
cgltf_result cgltf_load_buffers ( const cgltf_options options,
cgltf_data data,
const char *  gltf_path
)
void cgltf_node_transform_local ( const cgltf_node node,
cgltf_float out_matrix
)
void cgltf_node_transform_world ( const cgltf_node node,
cgltf_float out_matrix
)
cgltf_size cgltf_num_components ( cgltf_type  type)
cgltf_result cgltf_parse ( const cgltf_options options,
const void data,
cgltf_size  size,
cgltf_data **  out_data
)
cgltf_result cgltf_parse_file ( const cgltf_options options,
const char *  path,
cgltf_data **  out_data
)
cgltf_result cgltf_validate ( cgltf_data data)
